CAST NYLON SERIES DATA LIST

Product Details

No item unit Standrad MCNYLON OILON ENYLON GLASSF MOS2F
Density GB1033 1.15 1.15 1.15 1.35 1.15
Moisture adsorption %
IN AIR 1.8~2.0 1.8~2.0 2.0~2.2 1.65~1.83 1.9~2.0
IN WATER GB1034 6.3~6.5 6.3~6.5 6.6~6.8 3.5~4.1 6.1~6.3
Tensile strength Mpa
GB/T1040 89.0 75.30 69.5 130~150 74.1
elongation % GB/T1040 29.0 22.7 220.0 <20.0 25.0
Bending strength Mpa
GB9341 96.0 90.7 86.90 150.0 86.9
Compress strength Mpa
GB/T1040 85~100 85~100 85~100 110~130 90~105
Notched impact strength KJ/m2
GBT1043 5.7 6.4 9.6 5.5 6.4
Shore Dhardness
GB3398 80~85 80~85 80~85 85~90 80~88
Ball pressure hardness Mpa
GB3398 164.0 150.0 142.4 175.0 148.50
Friction coefficient µ
GB3360 0.4 0.113 0.131 0.45 0.107
Elastic modulus Gpa
GB/T1040 31.9 31.3 33.0 69.0 31.0
Melt point ℃
HG/T2235 223 223 223 260 230
Linear expanding coefficient *10-5
GB1036 7.5 7.5 7.5 2.5 7.5
Heat deformation ℃
GB1634 125 125 120 150 145
Volume electric resistance Ω.cm
GB1410 10*14 10*14 10*14 10*14 10*14
ARC resistance
ASTMD112 600 600 600 475 600
