S1—1" dia. cutting capacity; 1-400 cuts/min; 65 in/lb cutting torque; 1000, 1500 & 2000 RPM blade speeds
S2—2" dia. cutting capacity; 1-400 cuts/min; 136 in/lb cutting torque; 750, 1200 & 1500 RPM blade speeds
S3—3" dia. cutting capacity; 1-400 cuts/min; 203 in/lb cutting torque; 750, 1200 & 1500 RPM blade speeds
ACT (Adaptive Cutting Technology) Series Cutters, 1" to 3" cutting capacity; ACT software allows for operation up to 2,000 cuts/min; 240 in/lb cutting torque; 1000, 1500, & 2000 RPM blades speeds for on-demand cutting. A 6" color touch-screen interface is provided, making setup and operation quick and easy. ACT (Adaptive Cutting Technology) software automatically selects the proper operating mode based on line speed and cut length data entered by the operator. The system operates in the following modes:
On-Demand cutting – 0 to 400 cuts per minute. The knife is parked 180 degrees from the cut location. When triggered it rotates, cuts the material and stops, parked in the same position to provide the highest degree in cut length accuracy for on-demand cutting.
Cam cutting – 401 to 800 cuts per minute. For relatively high speed cutting, the knife rotates between the normal park position and the cut position at full speed. It then slows but does not stop as it approaches the normal park position. The speed of the cam action is computer controlled, and electronically linked to the speed of the feeder, allowing precise control of cut length.
