Gate design and placement are key factors in mold design. Types of gates, placement, and size significantly affect the outcome of molded part so should be understood for maximum benefit. Placement options for gates are often limited by design restrictions and other part-related constraints, understanding and utilizing industry best practices are useful in achieving optimal results.

Cold runner systems are an important aspect of mold design. By optimizing cold runner shapes and sizes, important molding processes such as pressure drops, polymer shearing, packing and cooling behavior, gate sealing time, and overall cycle time can be made more efficient as well.

Explanations, simulations, cause and effect analyses, and the uses of various design features are covered in this section. Understanding these design features is important because they influence the moldability, function, appearance, and quality of a part.
